New Top Quality Rack, Two Refurb'd Neve 3118 Preamp Modules, 1073/1084 Type EQ.

SKU: Neve.3118.rack
Stock: Out of Stock
Price:
$7000.00

Qty: - +
   - OR -

Here's a brand new custom rack with two Neve 3118 mic preamp channel strips. These are rare original discrete Neve modules from the mid 70's. It has mic and line inputs, individually switchable phantom power, and output level controls.

Both modules have had all electrolytic capacitors replaced and have been fully serviced and tested. The internal power supplies are high quality, open frame linear types. The custom enclosure is milled from heavy duty aluminum. The modules are securely fastened inside. The front panel labeling is engraved and filled with white paint. This is a great sounding two channel rack, built to last. Studio Electronics quality!

Module features include:

INPUTS
Mic preamp with 25 to 70 dB of gain, in 10 steps.
Line amp with -6 to +20 dB of gain, in 7 steps.

EQ
High frequency shelf with OFF, 3.3K,4.7K, 6.8K, 10K, and 15K settings, with +/- 15 dB cut or boost, continuously adjustable.
Mid frequency EQ with OFF, 270, 390, 560, 820, 1.2K, 1.8K, 2.7K, 3.9K, 5.6K, and 8.2K settings, with +/- 15 dB cut or boost, continuously adjustable.
Low frequency shelf with OFF, 33, 56, 100, 180, and 330 Hz. settings, with +/- 15 dB cut or boost, continuously adjustable.
High frequency filter with 3.9K, 5.6K, 8.2K, 12K, and 18K settings.
Low frequency filter with 27, 47, 82, and 150 Hz. settings.

EQ in/out switch
Phase reverse switch.

The power supplies are set up for 110-120 VAC 50/60 Hz. but can be jumpered for 240 volts. An AC power cord is included. The unit includes a complete 90 day parts and labor warranty.
